Product parameters:
Core material: Polymethyl methacrylate (PMMA)
Coating material: fluororesin
Sheath material: PE / PVC
Optical structure: step type
Numerical aperture: 0.5
Core refractive index: 1.49
Application wavelength: 650nm
Working temperature: -40-75 ℃
Application areas:
Industrial control signal transmission.
electric power equipment signal transmission.
Sensor signal transmission.
Signal transmission of consumer electronic products.
Automobile interior multimedia signal or control signal transmission.
Triple play or private LAN.
| Product level | Product number | outer diameter（MM） | Sheath material | attenuation(dB/km) | Numerical aperture | temperature range℃ | length（m) |
| SC-level optic cable | SC1000-2/6.0v | 2.2X4.4x6.0±0.20 | black PE | ≤180 | 0.5 | -55—+70 | 600 |
| SC1000-2 | 2.2X4.4±0.10 | black PE | ≤180 | 0.5 | -55—+70 | 1250 |
